2026 CIMARRON TRAILERS LS24G Livestock Trailer For Sale

Stock# 45724

New 2026 Cimarron LS24G Gooseneck Stock Trailer

Cimarron’s Lonestar series are the most durable aluminum livestock trailers available. Heavy duty construction and intelligent design ensure these trailers last.

Model:LS24G

Warranty:

• 8yr- Structural
• 3yr-Body and Hardware

Overall Equipment

• Dimensions:
  • Box Length: 26′ – 0″
  • Box Width: 8′ – 0″
  • Box Height: 6′ – 8″
  • GN Length: 8′ – 2″
  • GN Drop Wall: 50″ (For 4×4 Vehicle)
  • GN Structure: Medium Duty
• GVWR: 16000
• Undercarriage:
  • Axles: 8,000lb Dexter Torflex Axles, 8 Bolt Hubs w/ 5/8″ Studs
  • Brakes: Electric (All Wheel)
  • Tires: Cooper 245/70 R17.5″ LR-J
  • Wheels: 8 Hole-Aluminum Spoke 17.5″
• Trim: Lower Body: Rocker Panel, Full Length
• Coupler Type: 2 5/16″ Positive Lock w/ Adjustable HT Stem (GN STD)
• Design:
  • Nose Profile: Tapered Sides w/ 18″ r Corners
  • Nose Style: VP
  • Nose Sheet: Polished Stainless Steel
  • Side Walls: Extruded Side Slat w/ 2 Air Gaps w/ Plexiglass Insert & Tray
  • Sheet Color: Black
  • Roof Material: Insulated Roof Panel
• Flooring:
  • Type: Extruded Aluminum w/ V-truss & Cross Members Every 4″
  • Bottom Rail: HD-Bottom Rail
• Hardware: Hold Backs: All Doors & Gates
• Jack, Parking Type: Single Electric/Hydraulic w/ 12V Battery & Compartment
• Exterior Lights: Back-up LTS LED
  • Tail Lights: LED w/ Red Lens
  • Marker Lights: LED Button Type
  • Flood Lights: LED Awning Light 16″

Stall Area / Load Space Equipment

• Size: Length LH: 20′ – 0″
  • Length RH: 20′ – 0″
  • Width: 8′ – 0″
• Rear Opening: Type: Gate – Swing Type w/ Sliding Gate
  • Latch Type: HD-Steel Cam Lock
• Gates: 34″ Access Gate (LH)
  • Frame w/ 48″ Swinging Gate – No Threshold
• Ramps: Full Height x Up to 48″ Wide, Sealed w/ Black Latches

Special Requirements

1. Interior Tie Rail per FT
2. Center Gate 6″ Above Floor & store at partition wall
3. Tie rail, exterior, 1″ tube rh side just above rocker panel & below mid gap
4. Full height gate inside at side ramp & access  gate
5. Fan storage rails in gn, holds 4-24″ fans

We offer outstanding financing options, accept trades, and can arrange nationwide NO HASSLE delivery!

Inquire today for more information! (888) 333-6613

**We believe these specifications to be accurate. Any discrepancies are unintentional. Please verify information with a sales associate prior to purchase.**
