2027 PITTS TA20-T Equipment Trailer For Sale

Pitts TA20-T Tilt Tag Trailer – 20 Ton

General

• 20 Ton Capacity
• Model: TA20-T Tilt Tag
• Approx. Weight: 9,000 lbs
• Overall Length: 34’

Tongue / Drawbar

• 5’ Tongue – Continuation of Main Frame
• 3” Pintle Eye (4-Position Adjustable)
• Pintle Hitch Setting – 30” Adjustable
• Twin Two-Speed Landing Gear (50,000 lb Capacity)
• Tool Tray in Tongue
• Standard Safety Chains

Main Frame & Deck

• One-Piece Main Frame
• 14” Wide x 22# A572 Grade 50 High Tensile Steel
• 6” I-Beam Crossmembers (3.7 lbs/ft)
• C8” x 11.5 lb Side Rails
• 1-1/2” Nominal Apitong Wood Decking
• Partial Tilt Deck Design

Deck Dimensions

• Loaded Deck Height: 38”
• Stationary Deck: 4’ 4”
• Tilt Deck: 24’
• 13° Approach Angle
• Deck Width: 8’ 6”
• Full Apitong Wood Covered Floor

Axles & Suspension

• (2) 25,000 lb Axles
• Air Brakes with Auto Slack Adjusters
• ABS System
• 49” Axle Spacing
• Heavy Duty Mechanical Leaf Spring Suspension

Brakes / Tires / Wheels

• 12-1/4” x 7-1/2” Spring Brakes (2 Axle)
• (8) 215/75R17.5 Tires
• (8) Steel Disc Wheels

Electrical & Lighting

• Sealed Wiring Harness
• Full LED Lighting Package
• Marker Lights & Mid-Turn Signals
• (3) Oval Stop / Tail / Turn Lights Per Side (Rear)

Load Securement

• (12) Bent D-Rings

Finish

• White Metal Blast Prep
• PPG 2-Part Primer
• Red Paint Finish

Additional Information

We offer outstanding financing options, accept trades, and can arrange nationwide NO HASSLE delivery!

Inquire today for more information! (888) 333-6613

We believe these specifications to be accurate. Any discrepancies are unintentional. Please verify information with a sales associate prior to purchase.

Stock Number:46464
