MSRP:
$194,877
You Save:
$29,880
SALE PRICE:
$164,997
Estimated Payment w/ 10% Down*
*$16,500.00 Down**
*8.5% APR at 84 months**
$2,352* /mo.
With Approved Credit
No Floor Plan Available
| Number of Wheels | 12 |
| Axle Capacity | 25000 |
| Wheel Size | 22.5 |
| Coupler | KING PIN |
| F.E.T. | YES |
| Brakes | AIR |
| Main Deck Well | 30' |
110,000 lb. Capacity
56′ 4″ Overall Length (76′ 4″ Extended)
102″ Overall Width
30′ Main Deck (50′ Extended)
22″ Loaded Deck Height
6″ Ground Clearance
Hydraulic Detachable Non-Ground Bearing Gooseneck
Low Profile Arched Scraper Gooseneck with Air-Actuated Locking Pin
Five Position Adjustable Ride Height
16″ King Pin Setting
98″ Swing Clearance
100 KSI T1 Steel 4-Beam Fabricated Main Frame
Raised Apitong Wood Decking
Expanded Metal Front Tool Tray
Front Folding Loading Ramps with Traction Cleats
Recessed Bucket Well
Recessed Boom Well
12″ Removable Swing-Out Outriggers
1″ Forged Bent D-Rings Throughout Main Deck
Front & Rear Flag Holder Slots
Bolster Style Rear Deck
Flip Axle Ready Rear Frame
(3) 25,000 lb. Oil-Lubricated Air Ride Axles
Automatic Ride Height Controls with Manual Raise/Lower Valve
3rd Axle Lift
54.5″ Axle Spacing
77.5″ Axle Track Width
255/70R22.5 Load Range H Tires
Steel Hub-Piloted Disc Wheels
16½” × 7″ ABS Drum Brakes
4S2M ABS System
Automatic Slack Adjusters
30/30 Brake Chambers
Sealed 12V LED Lighting System
Black Epoxy Primer with Polyurethane Topcoat
13 HP Honda Power Unit with Dual Hydraulics
Hydraulic or Manual Flip Axle
Covered Center Deck
Bolt-On Boom Trough Plates
Heavy-Duty Diamond Plate Wheel Covers
Inner Aluminum Wheels
Outer Aluminum Wheels
275/70R22.5 Load Range J Tires
Battery Backup for Strobe
4″ Amber Strobe Light
10″ Gooseneck LED Light Bar
4th Additional Tail Light
Custom Paint
Covered Front Deck Toolbox
Liquid Filled Air Gauge
Registration Holder
36″ Flip Neck Extension
We offer outstanding financing options, accept trades, and can arrange nationwide NO HASSLE delivery! Inquire today for more information.
Call (888) 333-6613.
We believe these specifications to be accurate. Any discrepancies are unintentional. Please verify all information with a sales associate prior to purchase.
Stock Number:46971
